SolarPrimary option
100W Flexible Solar Panel Kit
Below This Baseline
Baseline comparison
Solar charging output: Solar charging output is below the estimated requirement by 275 W (100 W listed vs 375 W needed)
Recommended Solar Setup for a Sailboat
This guide uses a baseline daily energy assumption of 1,500 Wh/day for a typical example sailboat configuration. This is a sizing estimate, not a site-specific electrical design.
Power Requirement Summary
- Estimated daily energy
- 1,500 Wh/day
- Estimated peak AC load
- 800 W
- Estimated solar need
- 375 W
- Estimated battery need
- 1,667 Wh
- Estimated inverter need
- 1,000 W
Why This System Size
Solar array sizing
Using an estimated daily demand of 1,500 Wh, 5 peak sun hours, and a 80% system efficiency assumption, the estimated solar array need is approximately 375 W.
Battery sizing
With 1,500 Wh of daily use and an assumed 90% usable battery fraction per cycle, the estimated storage need is approximately 1,667 Wh. This accounts for not fully depleting the battery bank on a typical day.
Inverter sizing
Based on an estimated peak AC load of 800 W and a 1.25× surge margin, the estimated inverter need is approximately 1,000 W. This provides headroom for brief startup loads above continuous draw.
System Challenge
Corrosive saltwater spray exposure and high mast shadow movement
Marine environments expose equipment to salt spray and moving shade from masts, rigging, and dock structures. Corrosion-resistant hardware and flexible mounting options are practical considerations for this use case.
Equipment Comparison
SunPowerLogic compares published product specifications against the baseline sizing estimates shown above. Listed products may meet, fall below, or lack the data needed for a given requirement. This is not automatic product selection. Verify final compatibility with your specific loads and installation before purchasing.
Affiliate disclosure: Some equipment links below are affiliate links. SunPowerLogic may earn a commission from qualifying purchases at no additional cost to you.
View product details →View Product Details →
Inverter
Renogy Inverter PUH 2000W Pure Sine Wave Power Inverter
Matches This Baseline
Baseline comparison
Continuous AC output: Continuous AC output meets the estimated requirement (2,000 W vs 1,000 W needed)
Power System
Jackery Explorer 1000 V2
Partially Matches This Baseline
Baseline comparison
Battery capacity: Battery capacity is below the estimated requirement by 597 Wh (1,070 Wh listed vs 1,667 Wh needed)
Continuous AC output: Continuous AC output meets the estimated requirement (1,500 W vs 1,000 W needed)
