SolarPrimary option
Renogy 400W Monocrystalline Premium Kit
Below This Baseline
Baseline comparison
Solar charging output: Solar charging output is below the estimated requirement by 100 W (400 W listed vs 500 W needed)
Recommended Solar Setup for a Sprinter Van
This guide uses a baseline daily energy assumption of 2,000 Wh/day for a typical example sprinter van configuration. This is a sizing estimate, not a site-specific electrical design.
Power Requirement Summary
- Estimated daily energy
- 2,000 Wh/day
- Estimated peak AC load
- 1,200 W
- Estimated solar need
- 500 W
- Estimated battery need
- 2,223 Wh
- Estimated inverter need
- 1,500 W
Why This System Size
Solar array sizing
Using an estimated daily demand of 2,000 Wh, 5 peak sun hours, and a 80% system efficiency assumption, the estimated solar array need is approximately 500 W.
Battery sizing
With 2,000 Wh of daily use and an assumed 90% usable battery fraction per cycle, the estimated storage need is approximately 2,223 Wh. This accounts for not fully depleting the battery bank on a typical day.
Inverter sizing
Based on an estimated peak AC load of 1,200 W and a 1.25× surge margin, the estimated inverter need is approximately 1,500 W. This provides headroom for brief startup loads above continuous draw.
System Challenge
Shading from roof racks and roof vent obstruction layouts
Roof-mounted arrays on vans often lose output when racks, vents, or roof accessories cast partial shade across panels. Mounting layout and panel selection should account for intermittent shading across the day.
Equipment Comparison
SunPowerLogic compares published product specifications against the baseline sizing estimates shown above. Listed products may meet, fall below, or lack the data needed for a given requirement. This is not automatic product selection. Verify final compatibility with your specific loads and installation before purchasing.
Affiliate disclosure: Some equipment links below are affiliate links. SunPowerLogic may earn a commission from qualifying purchases at no additional cost to you.
View product details →View Product Details →
Inverter
Renogy Inverter PUH 2000W Pure Sine Wave Power Inverter
Matches This Baseline
Baseline comparison
Continuous AC output: Continuous AC output meets the estimated requirement (2,000 W vs 1,500 W needed)
Power System
EcoFlow DELTA 3 Ultra Plus
Matches This Baseline
Baseline comparison
Battery capacity: Battery capacity meets the estimated requirement (3,072 Wh vs 2,223 Wh needed)
Continuous AC output: Continuous AC output meets the estimated requirement (3,600 W vs 1,500 W needed)
